Sight Flow Indicators

Description

ACL sight flow indicators are designed for use in hygienic process pipelines in the Pharmaceutical, Biotech, Food & Beverage and Dairy industries. They provide a clear, reliable visual indication of fluid flow direction and flow presence within a pipeline, without compromising system hygiene or integrity.

ACL sight flow indicators are manufactured from 316L stainless steel and are fully compatible with ACL's range of hygienic clamps and fittings. They are available in a range of sizes to suit standard tube diameters and are designed to be easy to clean and inspect.

Specifications

Surface finish: 0.8Ra µm minimum (product contact surfaces)
Compatible with BS4825, DIN32676 and ISO1127 standards
Designed for CIP/SIP applications

Features

Clear borosilicate glass or polymer window for reliable flow visibility
316L stainless steel body as standard
Fully compatible with ACL tri-clamp fittings and gaskets
Designed for CIP/SIP cleaning processes
Available in a range of tube sizes
High-quality internal surface finish for hygienic performance

Materials

Body material: 316L Stainless Steel
Window material: Borosilicate glass or polymer
Seal materials: EPDM, Silicone, Viton available

Data Center

ACL products deliver strength, scalability, and long-term performance to meet the growing demands of advanced cooling and mechanical systems. Modular and configurable, our components support evolving data center layouts. Visit idealtridongroup.com/datacenters to explore ITG's full range of solutions. Use the contact form to reach our sales and engineering teams for product information, technical support, or a project quote.

Sight Flow Indicators

Industry PART#	Product Name	Standard	Type	Material Grade	Size (in)	Size DN	Pressure Rating (bar)	Pressure Rating (psi)	Weight
Pharmaceutical SCEKA1025127S46L	Clamp Type Sterile Visual Flow Indicator (1/2") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	1/2"		20	290.08	0.570000
View Page → Clamp Type Sterile Visual Flow Indicator (1/2") \| ASME BPE \| 316L GTIN: 840384323353 Legacy Part Number UK: SG.SC.050 - 1/2" CLAMP TYPE SVFI - 316L Legacy Part Number DK: CTSVFI0050SF4 Dimensional Image Key: Width (W) mm: 8 Window (A) x (W) mm: 24 x 8 ID (B) mm: 9.4 Mating Flange (C) mm: 25 Integral Flange (D) mm: 34 Length (L) mm: 76 Width (E) mm: 85 Minor OD (F) mm: 46.3 Major OD (G) mm: 136 Width (W) in: 0.31" Mating Flange (C) in: 0.98" Integral Flange (D) in: 1.34" ID (B) in: 0.37" Minor OD (F) in: 1.82" Major OD (G) in: 5.35" Window (A) x (W) in: 0.94" x 0.31" Window Height (A) mm: 24 Window Height (A) in: 0.94" Width (E) in: 3.35" Length (L) in: 2.99" ID mm: 9.4
Pharmaceutical SCEKA1025195S46L	Clamp Type Sterile Visual Flow Indicator (3/4") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	3/4"		17.5	253.82	0.890000
View Page → Clamp Type Sterile Visual Flow Indicator (3/4") \| ASME BPE \| 316L GTIN: 840384323377 Legacy Part Number UK: SG.SC.075 - 3/4" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1025195S46L Dimensional Image Key: Width (W) mm: 13 Window (A) x (W) mm: 29 x 13 ID (B) mm: 15.75 Mating Flange (C) mm: 25 Integral Flange (D) mm: 50.5 Length (L) mm: 87 Width (E) mm: 102 Minor OD (F) mm: 62.2 Major OD (G) mm: 154 Width (W) in: 0.51" Mating Flange (C) in: 0.98" Integral Flange (D) in: 1.99" ID (B) in: 0.62" Minor OD (F) in: 2.45" Major OD (G) in: 6.06" Window (A) x (W) in: 1.14" x 0.51" Window Height (A) mm: 29 Window Height (A) in: 1.14" Width (E) in: 4.02" Length (L) in: 3.43" ID mm: 15.75
Pharmaceutical SCEKA1050025S46L	Clamp Type Sterile Visual Flow Indicator (1") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	1"		8.5	123.28	1.025000
View Page → Clamp Type Sterile Visual Flow Indicator (1") \| ASME BPE \| 316L GTIN: 840384323391 Legacy Part Number UK: SG.SC.100 - 1" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1050025S46L Dimensional Image Key: Width (W) mm: 16 Window (A) x (W) mm: 34 x 16 ID (B) mm: 22.1 Mating Flange (C) mm: 50.5 Integral Flange (D) mm: 50.5 Length (L) mm: 90 Width (E) mm: 102 Minor OD (F) mm: 62.2 Major OD (G) mm: 154 Width (W) in: 0.63" Mating Flange (C) in: 1.99" Integral Flange (D) in: 1.99" ID (B) in: 0.87" Minor OD (F) in: 2.45" Major OD (G) in: 6.06" Window (A) x (W) in: 1.34" x 0.63" Window Height (A) mm: 34 Window Height (A) in: 1.34" Width (E) in: 4.02" Length (L) in: 3.54" ID mm: 22.1
Pharmaceutical SCEKA1050038S46L	Clamp Type Sterile Visual Flow Indicator (1 1/2") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	1 1/2"		8	116.03	1.170000
View Page → Clamp Type Sterile Visual Flow Indicator (1 1/2") \| ASME BPE \| 316L GTIN: 840384323414 Legacy Part Number UK: SG.SC.150 - 1 1/2" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1050038S46L Dimensional Image Key: Width (W) mm: 26 Window (A) x (W) mm: 48 x 26 ID (B) mm: 34.8 Mating Flange (C) mm: 50.5 Integral Flange (D) mm: 64 Length (L) mm: 105 Width (E) mm: 123 Minor OD (F) mm: 77.7 Major OD (G) mm: 186 Width (W) in: 1.02" Mating Flange (C) in: 1.99" Integral Flange (D) in: 2.52" ID (B) in: 1.37" Minor OD (F) in: 3.06" Major OD (G) in: 7.32" Window (A) x (W) in: 1.89" x 1.02" Window Height (A) mm: 48 Window Height (A) in: 1.89" Width (E) in: 4.84" Length (L) in: 4.13" ID mm: 34.8
Pharmaceutical SCEKA1050051S46L	Clamp Type Sterile Visual Flow Indicator (2") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	2"		7	101.53	1.510000
View Page → Clamp Type Sterile Visual Flow Indicator (2") \| ASME BPE \| 316L GTIN: 840384323438 Legacy Part Number UK: SG.SC.200 - 2" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1050051S46L Dimensional Image Key: Width (W) mm: 36 Window (A) x (W) mm: 55 x 36 ID (B) mm: 47.5 Mating Flange (C) mm: 64 Integral Flange (D) mm: 77.5 Length (L) mm: 120 Width (E) mm: 140 Minor OD (F) mm: 91.2 Major OD (G) mm: 200 Width (W) in: 1.42" Mating Flange (C) in: 2.52" Integral Flange (D) in: 3.05" ID (B) in: 1.87" Minor OD (F) in: 3.59" Major OD (G) in: 7.87" Window (A) x (W) in: 2.17" x 1.42" Window Height (A) mm: 55 Window Height (A) in: 2.17" Width (E) in: 5.51" Length (L) in: 4.72" ID mm: 47.5
Pharmaceutical SCEKA1077063S46L	Clamp Type Sterile Visual Flow Indicator (2 1/2") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	2 1/2"		6.5	94.27	1.880000
View Page → Clamp Type Sterile Visual Flow Indicator (2 1/2") \| ASME BPE \| 316L GTIN: 840384323452 Legacy Part Number UK: SG.SC.250 - 2 1/2" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1077063S46L Dimensional Image Key: Width (W) mm: 33 Window (A) x (W) mm: 72 x 33 ID (B) mm: 60.2 Mating Flange (C) mm: 77.5 Integral Flange (D) mm: 91 Length (L) mm: 151 Width (E) mm: 150 Minor OD (F) mm: 104.7 Major OD (G) mm: 212 Width (W) in: 1.3" Mating Flange (C) in: 3.05" Integral Flange (D) in: 3.58" ID (B) in: 2.37" Minor OD (F) in: 4.12" Major OD (G) in: 8.35" Window (A) x (W) in: 2.83" x 1.3" Window Height (A) mm: 72 Window Height (A) in: 2.83" Width (E) in: 5.91" Length (L) in: 5.94" ID mm: 60.2
Pharmaceutical SCEKA1091076S46L	Clamp Type Sterile Visual Flow Indicator (3") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	3"		6.5	94.27	2.480000
View Page → Clamp Type Sterile Visual Flow Indicator (3") \| ASME BPE \| 316L GTIN: 840384323476 Legacy Part Number UK: SG.SC.300 - 3" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1091076S46L Dimensional Image Key: Width (W) mm: 36 Window (A) x (W) mm: 108 x 36 ID (B) mm: 72.9 Mating Flange (C) mm: 91 Integral Flange (D) mm: 106 Length (L) mm: 175 Width (E) mm: 165 Minor OD (F) mm: 119.7 Major OD (G) mm: 226 Width (W) in: 1.42" Mating Flange (C) in: 3.58" Integral Flange (D) in: 4.17" ID (B) in: 2.87" Minor OD (F) in: 4.71" Major OD (G) in: 8.9" Window (A) x (W) in: 4.25" x 1.42" Window Height (A) mm: 108 Window Height (A) in: 4.25" Width (E) in: 6.5" Length (L) in: 6.89" ID mm: 72.9
Pharmaceutical SCEKA1119101S46L	Clamp Type Sterile Visual Flow Indicator (4") \| ASME BPE \| 316L	ASME BPE	Clamp Type Sterile Visual Flow Indicator	316L	4"		4	58.02	3.380000
View Page → Clamp Type Sterile Visual Flow Indicator (4") \| ASME BPE \| 316L GTIN: 840384323490 Legacy Part Number UK: SG.SC.400 - 4" CLAMP TYPE SVFI - 316L Legacy Part Number DK: SCEKA1119101S46L Dimensional Image Key: Width (W) mm: 48 Window (A) x (W) mm: 135 x 48 ID (B) mm: 97.38 Mating Flange (C) mm: 119 Integral Flange (D) mm: 130 Length (L) mm: 200 Width (E) mm: 191 Minor OD (F) mm: 143.7 Major OD (G) mm: 256 Width (W) in: 1.89" Mating Flange (C) in: 4.69" Integral Flange (D) in: 5.12" ID (B) in: 3.83" Minor OD (F) in: 5.66" Major OD (G) in: 10.08" Window (A) x (W) in: 5.31" x 1.89" Window Height (A) mm: 135 Window Height (A) in: 5.31" Width (E) in: 7.52" Length (L) in: 7.87" ID mm: 97.38
Pharmaceutical SVEKA1025952S46L	Sterile Visual Flow Indicator (3/8") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	3/8"		22	319.08	0.083500
View Page → Sterile Visual Flow Indicator (3/8") \| ASME BPE \| 316L GTIN: 840384323537 Legacy Part Number UK: SG.SV.038 - 3/8" STERILE VISUAL FLOW Legacy Part Number DK: SGSV038SF1 Dimensional Image Key: Width (W) mm: 8 Window (A) x (W) mm: 16 x 8 ID (B) mm: 7.7 Mating Flange (C) mm: 25.4 Length (L) mm: 65 Width (E) mm: 0.09 Width (W) in: 0.31" Mating Flange (C) in: 1" ID (B) in: 0.3" Window (A) x (W) in: 0.63" x 0.31" Window Height (A) mm: 16 Window Height (A) in: 0.63" Length (L) in: 2.56" ID mm: 7.7
Pharmaceutical SVEKA1025127S46L	Sterile Visual Flow Indicator (1/2") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	1/2"		20	290.08	0.120000
View Page → Sterile Visual Flow Indicator (1/2") \| ASME BPE \| 316L GTIN: 840384323551 Legacy Part Number UK: SG.SV.050 - 1/2" STERILE VISUAL FLOW Legacy Part Number DK: SGSV050SF1 Dimensional Image Key: Width (W) mm: 9 Window (A) x (W) mm: 20 x 9 ID (B) mm: 9.5 Mating Flange (C) mm: 25.4 Length (L) mm: 76 Width (E) mm: 0.12 Width (W) in: 0.35" Mating Flange (C) in: 1" ID (B) in: 0.37" Window (A) x (W) in: 0.79" x 0.35" Window Height (A) mm: 20 Window Height (A) in: 0.79" Length (L) in: 2.99" ID mm: 9.5
Pharmaceutical SVEKA1025195S46L	Sterile Visual Flow Indicator (3/4") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	3/4"		17.5	253.82	0.150000
View Page → Sterile Visual Flow Indicator (3/4") \| ASME BPE \| 316L GTIN: 840384323575 Legacy Part Number UK: SG.SV.075 - 3/4" STERILE VISUAL FLOW Legacy Part Number DK: SGSV075SF4 Dimensional Image Key: Width (W) mm: 11 Window (A) x (W) mm: 27 x 11 ID (B) mm: 15.8 Mating Flange (C) mm: 25.4 Length (L) mm: 87 Width (E) mm: 0.15 Width (W) in: 0.43" Mating Flange (C) in: 1" ID (B) in: 0.62" Window (A) x (W) in: 1.06" x 0.43" Window Height (A) mm: 27 Window Height (A) in: 1.06" Length (L) in: 3.43" ID mm: 15.8
Pharmaceutical SVEKA1050025S46L	Sterile Visual Flow Indicator (1") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	1"		8.5	123.28	0.373400
View Page → Sterile Visual Flow Indicator (1") \| ASME BPE \| 316L GTIN: 840384323599 Legacy Part Number UK: SG.SV.100 - 1" STERILE VISUAL FLOW Legacy Part Number DK: SGSV100SF1 Dimensional Image Key: Width (W) mm: 16 Window (A) x (W) mm: 30 x 16 ID (B) mm: 22.1 Mating Flange (C) mm: 50.5 Length (L) mm: 91 Width (E) mm: 0.37 Width (W) in: 0.63" Mating Flange (C) in: 1.99" ID (B) in: 0.87" Window (A) x (W) in: 1.18" x 0.63" Window Height (A) mm: 30 Window Height (A) in: 1.18" Length (L) in: 3.58" ID mm: 22.1
Pharmaceutical SVEKA1050038S46L	Sterile Visual Flow Indicator (1 1/2") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	1 1/2"		8	116.03	0.398000
View Page → Sterile Visual Flow Indicator (1 1/2") \| ASME BPE \| 316L GTIN: 840384323612 Legacy Part Number UK: SG.SV.150 - 1 1/2" STERILE VISUAL FLOW Legacy Part Number DK: SGSV150SF1 Dimensional Image Key: Width (W) mm: 24 Window (A) x (W) mm: 40 x 24 ID (B) mm: 34.8 Mating Flange (C) mm: 50.5 Length (L) mm: 105 Width (E) mm: 0.4 Width (W) in: 0.94" Mating Flange (C) in: 1.99" ID (B) in: 1.37" Window (A) x (W) in: 1.57" x 0.94" Window Height (A) mm: 40 Window Height (A) in: 1.57" Length (L) in: 4.13" ID mm: 34.8
Pharmaceutical SVEKA1064051S46L	Sterile Visual Flow Indicator (2") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	2"		7	101.53	0.640000
View Page → Sterile Visual Flow Indicator (2") \| ASME BPE \| 316L GTIN: 840384323636 Legacy Part Number UK: SG.SV.200 - 2" STERILE VISUAL FLOW Legacy Part Number DK: SGSV200SF1 Dimensional Image Key: Width (W) mm: 34 Window (A) x (W) mm: 48 x 34 ID (B) mm: 47.5 Mating Flange (C) mm: 64 Length (L) mm: 120 Width (E) mm: 0.63 Width (W) in: 1.34" Mating Flange (C) in: 2.52" ID (B) in: 1.87" Window (A) x (W) in: 1.89" x 1.34" Window Height (A) mm: 48 Window Height (A) in: 1.89" Length (L) in: 4.72" ID mm: 47.5
Pharmaceutical SVEKA1077063S46L	Sterile Visual Flow Indicator (2 1/2") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	2 1/2"		6.5	94.27	1.290000
View Page → Sterile Visual Flow Indicator (2 1/2") \| ASME BPE \| 316L GTIN: 840384323650 Legacy Part Number UK: SG.SV.250 - 2 1/2" STERILE VISUAL FLOW Legacy Part Number DK: SGSV250SF1 Dimensional Image Key: Width (W) mm: 40 Window (A) x (W) mm: 55 x 40 ID (B) mm: 60.3 Mating Flange (C) mm: 77.5 Length (L) mm: 151 Width (E) mm: 1.15 Width (W) in: 1.57" Mating Flange (C) in: 3.05" ID (B) in: 2.37" Window (A) x (W) in: 2.17" x 1.57" Window Height (A) mm: 55 Window Height (A) in: 2.17" Length (L) in: 5.94" ID mm: 60.3
Pharmaceutical SVEKA1091076S46L	Sterile Visual Flow Indicator (3") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	3"		6.5	94.27	1.550000
View Page → Sterile Visual Flow Indicator (3") \| ASME BPE \| 316L GTIN: 840384323674 Legacy Part Number UK: SG.SV.300 - 3" STERILE VISUAL FLOW Legacy Part Number DK: SGSV300SF4 Dimensional Image Key: Width (W) mm: 50 Window (A) x (W) mm: 90 x 50 ID (B) mm: 72.9 Mating Flange (C) mm: 91 Length (L) mm: 175 Width (E) mm: 1.46 Width (W) in: 1.97" Mating Flange (C) in: 3.58" ID (B) in: 2.87" Window (A) x (W) in: 3.54" x 1.97" Window Height (A) mm: 90 Window Height (A) in: 3.54" Length (L) in: 6.89" ID mm: 72.9
Pharmaceutical SVEKA1119101S46L	Sterile Visual Flow Indicator (4") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	4"		4	58.02	2.783700
View Page → Sterile Visual Flow Indicator (4") \| ASME BPE \| 316L GTIN: 840384323698 Legacy Part Number UK: SG.SV.400 - 4" STERILE VISUAL FLOW Legacy Part Number DK: SGSV400SF1 Dimensional Image Key: Width (W) mm: 60 Window (A) x (W) mm: 110 x 60 ID (B) mm: 97.4 Mating Flange (C) mm: 119 Length (L) mm: 200 Width (E) mm: 2.78 Width (W) in: 2.36" Mating Flange (C) in: 4.69" ID (B) in: 3.83" Window (A) x (W) in: 4.33" x 2.36" Window Height (A) mm: 110 Window Height (A) in: 4.33" Length (L) in: 7.87" ID mm: 97.4
Pharmaceutical SVEKA1167152S46L	Sterile Visual Flow Indicator (6") \| ASME BPE \| 316L	ASME BPE	Sterile Visual Flow Indicator	316L	6"		3	43.51	6.986000
View Page → Sterile Visual Flow Indicator (6") \| ASME BPE \| 316L GTIN: 840384323711 Legacy Part Number UK: SG.SV.600 - 6" STERILE VISUAL FLOW Legacy Part Number DK: SGSV600SF1 Dimensional Image Key: Width (W) mm: 80 Window (A) x (W) mm: 150 x 80 ID (B) mm: 150 Mating Flange (C) mm: 167 Length (L) mm: 250 Width (E) mm: 6 Width (W) in: 3.15" Mating Flange (C) in: 6.57" ID (B) in: 5.91" Window (A) x (W) in: 5.91" x 3.15" Window Height (A) mm: 150 Window Height (A) in: 5.91" Length (L) in: 9.84" ID mm: 150
Pharmaceutical SVEKDA034013S46L	Sterile Visual Flow Indicator (DN 10) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 10	28	406.11	0.190000
View Page → Sterile Visual Flow Indicator (DN 10) \| DIN 32676 Table A \| 316L GTIN: 840384323735 Legacy Part Number UK: SG.SV.D010 - DIN 10 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD010 Dimensional Image Key: Width (W) mm: 20 Window (A) x (W) mm: 10 x 20 ID (B) mm: 10 Mating Flange (C) mm: 34 Length (L) mm: 80 Flange (C) mm: 34 Width (W) in: 0.79" Mating Flange (C) in: 1.34" ID (B) in: 0.39" Window (A) x (W) in: 0.39" x 0.79" Window Height (A) mm: 10 Window Height (A) in: 0.39" Length (L) in: 3.15" ID mm: 10
Pharmaceutical SVEKDA034019S46L	Sterile Visual Flow Indicator (DN 15) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 15	18	261.07	0.210000
View Page → Sterile Visual Flow Indicator (DN 15) \| DIN 32676 Table A \| 316L GTIN: 840384323759 Legacy Part Number UK: SG.SV.D015 - DIN 15 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD015 Dimensional Image Key: Width (W) mm: 27 Window (A) x (W) mm: 12.5 x 27 ID (B) mm: 16 Mating Flange (C) mm: 34 Length (L) mm: 87 Flange (C) mm: 34 Width (W) in: 1.06" Mating Flange (C) in: 1.34" ID (B) in: 0.63" Window (A) x (W) in: 0.49" x 1.06" Window Height (A) mm: 12.5 Window Height (A) in: 0.49" Length (L) in: 3.43" ID mm: 16
Pharmaceutical SVEKDA034023S46L	Sterile Visual Flow Indicator (DN 20) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 20	15	217.56	0.210000
View Page → Sterile Visual Flow Indicator (DN 20) \| DIN 32676 Table A \| 316L GTIN: 840384323773 Legacy Part Number UK: SG.SV.D020 - DIN 20 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD020 Dimensional Image Key: Width (W) mm: 30 Window (A) x (W) mm: 15 x 30 ID (B) mm: 20 Mating Flange (C) mm: 34 Length (L) mm: 90 Flange (C) mm: 34 Width (W) in: 1.18" Mating Flange (C) in: 1.34" ID (B) in: 0.79" Window (A) x (W) in: 0.59" x 1.18" Window Height (A) mm: 15 Window Height (A) in: 0.59" Length (L) in: 3.54" ID mm: 20
Pharmaceutical SVEKDA050029S46L	Sterile Visual Flow Indicator (DN 25) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 25	12.9	187.1	0.366000
View Page → Sterile Visual Flow Indicator (DN 25) \| DIN 32676 Table A \| 316L GTIN: 840384323797 Legacy Part Number UK: SG.SV.D025 - DIN 25 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD025 Dimensional Image Key: Width (W) mm: 38 Window (A) x (W) mm: 19 x 38 ID (B) mm: 26 Mating Flange (C) mm: 50.5 Length (L) mm: 95 Flange (C) mm: 50.5 Width (W) in: 1.5" Mating Flange (C) in: 1.99" ID (B) in: 1.02" Window (A) x (W) in: 0.75" x 1.5" Window Height (A) mm: 19 Window Height (A) in: 0.75" Length (L) in: 3.74" ID mm: 26
Pharmaceutical SVEKDA050035S46L	Sterile Visual Flow Indicator (DN 32) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 32	10.9	158.09	0.340000
View Page → Sterile Visual Flow Indicator (DN 32) \| DIN 32676 Table A \| 316L GTIN: 840384323810 Legacy Part Number UK: SG.SV.D032 - DIN 32 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD032 Dimensional Image Key: Width (W) mm: 42 Window (A) x (W) mm: 23.5 x 42 ID (B) mm: 32 Mating Flange (C) mm: 50.5 Length (L) mm: 102 Flange (C) mm: 50.5 Width (W) in: 1.65" Mating Flange (C) in: 1.99" ID (B) in: 1.26" Window (A) x (W) in: 0.93" x 1.65" Window Height (A) mm: 23.5 Window Height (A) in: 0.93" Length (L) in: 4.02" ID mm: 32
Pharmaceutical SVEKDA050041S46L	Sterile Visual Flow Indicator (DN 40) \| DIN 32676 Table A \| 316L	DIN 32676 Table A	Sterile Visual Flow Indicator	316L		DN 40	10.9	158.09	0.380000
View Page → Sterile Visual Flow Indicator (DN 40) \| DIN 32676 Table A \| 316L GTIN: 840384323834 Legacy Part Number UK: SG.SV.D040 - DIN 40 STERILE VISUAL FLOW Legacy Part Number DK: SGSVD040 Dimensional Image Key: Width (W) mm: 51 Window (A) x (W) mm: 28 x 51 ID (B) mm: 38 Mating Flange (C) mm: 50.5 Length (L) mm: 108 Flange (C) mm: 50.5 Width (W) in: 2.01" Mating Flange (C) in: 1.99" ID (B) in: 1.5" Window (A) x (W) in: 1.1" x 2.01" Window Height (A) mm: 28 Window Height (A) in: 1.1" Length (L) in: 4.25" ID mm: 38
